Electric Skateboard Hub Motor

Lowest Price of the Year 🏷️

"Black Friday" Price Guarantee 🔒

electric skateboard hub motor

Powered by HOBBYWING

Built with the renowned HOBBYWING motor, this system delivers powerful performance and rapid heat dissipation. Its high-quality design is durable and virtually maintenance-free, giving you a reliable ride every time.

electric skateboard hub motor

High Torque, Silent Ride

Experience explosive torque that lets you conquer any road, from city streets to rough terrain. The motor runs whisper-quiet, delivering smooth power so you can focus on the joy of the ride.

SPECS
ModelM3M4M7
Motor Case Diameter75 mm90 mm165 mm
Rated Power300 Watts650 Watts1500 Watts
Motor Width65 mm60 mm55 mm
Motor Weight748 g737 g1776 g
Charging Voltage42V, 2A50.4V, 3A42V, 2A
MatchingMax OneMax2 Pro / Cyber Max / Cyber Mini / Cyber Mini Air / Cyber Kit (Hub Motor)
Cyber Ultra (Hub Motor)
Motor Type4230-65KV5230-70KV9620-33KV
Temperature Sensor TypeNTC 10KNTC 10KNTC 10K
Motor Max Power350 Watts1200 Watts2000 Watts
Operating Voltage Range7~10s Lipo 24~36V10-12s Lipo10-12s Lipo
Max Torque3 N.m5 N.m12 N.m
Max Efficiency85%87%89%
Resistance (25℃)240 mΩ240 mΩ268 mΩ
WaterproofIP54IP54IP54
Removable Cover Tyre√√√
