Maxfind Hub Motors

Name: Maxfind Hub Motors
Brand: Maxfind
SKU: M3-left
Price: 79.0 USD
Availability: InStock

$79.00 USD

Our 8th generation of hub motor skateboard will provide you with the safest, highest efficiency and highest performance skateboarding experience.

Type:

75mm (M3)

Variant

Quantity:

SHIPPING

WARRANTY

Maxfind have strong faith with our design & quality. We provide 270 days warranty.

$79.00 USD

Model	M3	M4	M5	M6	M7
Motor Case Diameter	75 mm	90 mm	96 mm	165 mm	165 mm
Rated Power	300 Watts	650 Watts	750 Watts	1200 Watts	1500 Watts
Motor Width	65 mm	60 mm	60 mm	55 mm	55 mm
Motor Weight	748 g	737 g	781 g	1776 g	1776 g
Matching	MAX ONE	MAX5 PRO / MAX2 PRO	FF STREET / M5 DRIVE KIT	FF PLUS	FF AT
Motor Type	4230-65KV	5230-70KV	5230-72KV	9620-33KV	9620-33KV
Temperature Sensor Type	NTC 10K	NTC 10K	NTC 10K	NTC 10K	NTC 10K
Motor Max Power	350 Watts	1200 Watts	1500 Watts	2000 Watts	2000 Watts
Operating Voltage Range	7~10s Lipo 24~36V	10-12s Lipo	10-12s Lipo	10-12s Lipo	10-12s Lipo
Max Torque	3 N.m	5 N.m	5.2 N.m	12 N.m	12 N.m
Max Efficiency	85%	87%	89%	89%	89%
Resistance (25℃)	240 mΩ	240 mΩ	236 mΩ	268 mΩ	268 mΩ
Waterproof	IP54	IP54	IP54	IP54	IP54
Removable Cover Tyre	√	√	√	√	√
Matching	MAX ONE	MAX5 PRO / MAX2 PRO	FF STREET / M5 DRIVE KIT	FF PLUS	FF AT
